Flange Sight Glasses

Flange sight glasses is comprised of stainless steel frame and tempered glass. Through it, operator can observe the flowing of the media clearly and precisely in the fields of food, cosmetics, pharmaceutical and fine chemicals industries.


Technical specifications

  • Size from 1.5″-8″-DN40-DN200
  • Assemble flange with glass by using hexagon socket bolts
  • Gasket material: PTFE in accordance with FAD 177.1600 Material: AISI 304(1.4301) AISI 316L(1.4404) ◆Max.
  • Temperature: -10°C-120°C
  • Max. Pressure: 10bar


Function Options

  • Wireless power supply, one charging can use 2-3 months (Depending on the frequency) ●Cable power supply AC110V-220V, one charging can use 2-3 months (Depending on the frequency)
  • Cable power supply DC24V
  • No retention, zero dead angle, high light, white cold light source,waterproof, explosion-proof
